5000 Gallon 15 Degree Plastic Cone Bottom Tank in Black
SKU
SII-8050200N49
Manufacturer Part
8050200N49
$8055.00
Snyder cone bottom tanks are available in various slopes—30°, 45°, and 60°—with capacities ranging from 15 to 13,000 gallons, offering material options tailored to diverse application needs. These tanks, designed for durability and safety, feature specific gravity ratings up to 1.9 and optional seismic and wind restraint systems.
ADD-ONS
We suggest these additional items.
5000 Gallon 15 Degree Plastic Cone Bottom Tank in Black
Snyder cone bottom tanks are perfect for applications involving liquid storage, material separation, and settling processes. They are commonly used in industries like agriculture, water treatment, and chemical manufacturing, where efficient drainage and easy maintenance are critical.
- Constructed with durable, rotationally molded polyethylene resin, ensuring resistance to cracks, chips, and ruptures.
- Built with materials that meet FDA standards for safe-food grade storage, ensuring compliance and safety.
- Equipped with UV inhibitors to protect liquid contents from direct sunlight, suitable for indoor and outdoor use.
- Maximum operating temperature recommended is 100°F.
| Dimensions | |
|---|---|
| Diameter | 102" |
| Length | 102" |
| Width | 102" |
| Height | 176" |
| Weight | 550lbs |
| Lid Size | 18" |
| Key Specs | |
|---|---|
| Manufacturer | Snyder Industries |
| Color | Black |
| Gallon Capacity | 5000 |
| Specific Gravity | 1.5 (Max 12.52 lbs/gal) |
| Cone Degree | 15 |
| Material | High Density Linear Polyethylene |
| Max Temperature | 120 F/ 48 C |
| Certifications & Compliances | ANSI / NSF 61 Approved, FDA Approved |
| Warranty | 3 years |
| Shipping Height | 102" |
| Shipping Length | 176" |
| Shipping Weight | 550lbs |
| Shipping Width | 102" |
| Ship Class | OVS |
| NMFC Code | 156600 |
