4035 Gallon HDPE Horizontal Elliptical Leg Tank in Blue

Manufacturer Part
ADD-ONS We suggest these additional items.
This heavy duty elliptical tank is made from polyethylene and is designed to be used above ground water, for liquid transportation (potable water also) and storage applications. Posses UV inhibitors to keep content safe for longer time.

Accuracy of the images may vary. Refer to the specifications table to ensure precision.

4035 Gallon Heavy Duty Light Blue Elliptical Leg Tank

Norwesco Industries is a leading North American manufacturer of proprietary rotationally molded polyethylene elliptical leg tanks for above ground water & liquid transport & storage applications.

Leg Tank Specifications:
Lid Size:16" Vented Hinged Manway
Outlet:3" Female NPT Bulkhead Fitting w/ 2" Reducer & Siphon Tube
Can Outlet Be Upsized:Yes By Request. 4" Maximum (additional charge)
Additional Fittings:Available By Request
Specific Gravity:1.9 (15.85 lbs. per gallon)
Tie Down Hoops:Yes (4) (Sold Separately) (Required For Warranty)
Ladder:Yes (Sold Separately)
Gallon Markers:Yes
UV InhibitorsYes
Colors:Light Blue. Black
Translucent:(Yes - Light Blue) (No - Black)
FDA Approved:Yes - Complies with FDA regulation 21 CRF 177.1520 (1) 3.1 and 3.2
ANSI / NSF 61 Approved Resin:Yes
NSF Sticker Availability Locations:California. Ohio. Texas
Uses:Liquids & Potable Water Transport or Stationary
DOT Approved:No
Sits Flat:Yes

Elliptical Leg Tanks are for storage and are not designed to be pressurized.
Requires full length support & support bands (hoops).
Technical Drawings
View Technical Drawing

Key Specs
Gallon Capacity 4035
Lid Size 16"
Specific Gravity 1.9
Orientation Horizontal
Length 192"
Width 92"
Height 75"
Weight 1320lbs
Manufacturer Norwesco
Manufacturer Part Number 41269
Color Blue
Shipping Height 75"
Shipping Length 192"
Shipping Weight 1320lbs
Shipping Width 92"
Ship Class OVS
