300 Gallon Galvanized Steel Vertical Water Storage Tank

SKU
TM-MT300G-WS
Manufacturer Part
MT300G-WS
$1,615.38

Accuracy of the images may vary. Refer to the specifications table to ensure precision.

300 Gallon Galvanized Water Tank


Tanks are constructed of 20 gauge G-90 galvanized steel.
Galvanized tanks are lined with a paint/epoxy to protect the metal. This is FDA approved for potable water and meets ANSI/NSF 61 specifications. Galvanized tanks have a warranty of 1 year.
Tanks should be installed on a solid base. Concrete pads or crushed granite are well suited.

Water Storage Standard Package includes:
  • 1 – 16” vented lid
  • 2 – 2” fittings (inlet/outlet)


Additional Shipment Preparation Fee Required: $50
The Shipment Preparation Fee is per tank and includes materials and packaging of the tank to prevent damage during transit.
Technical Documents
View Technical Drawing

Key Specs
Gallon Capacity 300
Lid Size 8"
Dimensions
Length 36"
Width 36"
Height 68"
Weight 150lbs
General
Material Steel
Manufacturer Texas Metal Tanks
Manufacturer Part Number MT300G-WS
Disclaimers A 12" strainer basket and 3" overflow are included with tanks under 2600gal. Anything larger will come with a 16" strainer basket and a 4" overflow.
Shipping Height 68"
Shipping Length 36"
Shipping Weight 150lbs
Shipping Width 36"
Ship Class LTL
NMFC Code 104600
